Siemens SINAMICS S Series - p3056[0...n] Motor identification - stator leakage inductance; MotId L_stat leak; p3058[0...n] Motor identification - rotor leakage inductance; MotId L_rot leak; p3060[0...n] Motor identification - magnetizing inductance; MotId Lh; p3070 Motor identification - voltage emulation error final value; MotId V_err final

List of parameters
Parameters
1-691
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Stator leakage inductance (induction motor, separately-excited synchronous motor) or quadrature stator inductance
(synchronous motor) of the motor measured from the motor identification
Note: The parameter is automatically preset for motors from the motor list (p0301).
Description: Rotor leakage inductance of the motor measured from the motor identification.
Note: The parameter is not used for synchronous motors (p0300 = 2xx).
Description: Magnetizing inductance of the motor measured from the motor identification.
Note: The parameter is not used for synchronous motors (p0300 = 2xx).
Description: Final value to compensate the voltage emulation error set from the motor identification.
Description: Current offset to compensate the voltage emulation error set by the motor identification.
p3056[0...n] Motor identification - stator leakage inductance / MotId L_stat leak
SERVO Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: Motor identification Units group: 15_1 Unit selection: p0349
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00000 [mH] 1000.00000 [mH] 0.00000 [mH]
p3058[0...n] Motor identification - rotor leakage inductance / MotId L_rot leak
SERVO Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: Motor identification Units group: 15_1 Unit selection: p0349
Not for motor type: PEM, REL Expert list: 1
Min Max Factory setting
0.00000 [mH] 1000.00000 [mH] 0.00000 [mH]
p3060[0...n] Motor identification - magnetizing inductance / MotId Lh
SERVO Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: Motor identification Units group: 15_1 Unit selection: p0349
Not for motor type: PEM, REL Expert list: 1
Min Max Factory setting
0.00000 [mH] 10000.00000 [mH] 0.00000 [mH]
p3070 Motor identification - voltage emulation error final value / MotId V_err final
SERVO (Exp M_ctrl) Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.000 [V] 100.000 [V] 0.000 [V]
p3071 Motor identification - voltage emulation error current offset / MotId V_err I_offs
SERVO (Exp M_ctrl) Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.000 [A] 100.000 [A] 0.000 [A]
