Parameters

List of parameters

1-546

SINAMICS S List Manual (LH1), 07/2007

[6] = PZD 7 + 8

[7] = PZD 8 + 9

[8] = PZD 9 +10

[9] = PZD 10 + 11

[10] = PZD 11 + 12

[11] = PZD 12 + 13

[12] = PZD 13 + 14

[13] = PZD 14 + 15

[14] = PZD 15 + 16

[15] = PZD 16 + 17

[16] = PZD 17 + 18

[17] = PZD 18 + 19

[18] = PZD 19 + 20

[19] = PZD 20 + 21

[20] = PZD 21 + 22

[21] = PZD 22 + 23

[22] = PZD 23 + 24

[23] = PZD 24 + 25

[24] = PZD 25 + 26

[25] = PZD 26 + 27

[26] = PZD 27 + 28

[27] = PZD 28 + 29

[28] = PZD 29 + 30

[29] = PZD 30 + 31

[30] = PZD 31 + 32

Dependency: Refer to: p2051

Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.

Note: IF1: Interface 1

Description: Displays the PZD (actual values) with double word format sent to the PROFIBUS/PROFINET master.

Index: [0] = PZD 1 + 2

[1] = PZD 2 + 3

[2] = PZD 3 + 4

[3] = PZD 4 + 5

[4] = PZD 5 + 6

[5] = PZD 6 + 7

[6] = PZD 7 + 8

[7] = PZD 8 + 9

[8] = PZD 9 +10

[9] = PZD 10 + 11

[10] = PZD 11 + 12

[11] = PZD 12 + 13

[12] = PZD 13 + 14

[13] = PZD 14 + 15

[14] = PZD 15 + 16

r2063[0...14] IF1 PROFIdrive diagnostics PZD send double word / IF1 diag send DW

SERVO, TM41 Can be changed: - Calculated: - Access level: 3

Data type: Unsigned32 Dynamic index: - Func. diagram: 2450, 2470

P-Group: Communications Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 On Off -

01 Bit 1 On Off -

02 Bit 2 On Off -

03 Bit 3 On Off -

04 Bit 4 On Off -

05 Bit 5 On Off -

06 Bit 6 On Off -
