List of parameters
Parameters
1-991
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the number of signal sources from this drive to other drives/drive objects (Binector Output/Connector Out-
put, BO/CO).
Dependency: Refer to: r9491, r9492, p9493
Description: Displays the signal receiver list (Binector Input/Connector Input, BI/CI) for the first interconnections between this
drive and other drives/drive objects.
Dependency: Refer to: r9490, r9492, p9493
Notice: A drive cannot be deleted if this list is not empty! Otherwise, another drive would continue to attempt to read a sig-
nal from a drive that no longer existed.
Note: All indices of r9491 to p9493 designate the same interconnection.
r9491[x] contains the signal receiver and r9492[x] the matching signal source; p9493[x] can be set to modify the
interconnection.
Description: Displays the signal source list (Binector Output/Connector Output, BO/CO) for the first interconnections between
this drive and other drives/drive objects.
Dependency: Refer to: r9490, r9491, p9493
Notice: A drive cannot be deleted if this list is not empty! Otherwise, another drive would continue to attempt to read a sig-
nal from a drive that no longer existed.
Note: All indices of r9491 to p9493 designate the same interconnection.
r9491[x] contains the signal receiver and r9492[x] the matching signal source; p9493[x] can be set to modify the
interconnection.
Description: Setting to reset the BICO interconnections to other drives. Each interconnection can be individually reset.
r9490 Number of BICO interconnections to other drives / Qty BICO to drive
All objects Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r9491[0...9] BI/CI of BICO interconnections to other drives / BI/CI to drive
All objects Can be changed: - Calculated: - Access level: 3
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r9492[0...9] BO/CO of BICO interconnections to other drives / BO/CO to drive
All objects Can be changed: - Calculated: - Access level: 3
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
p9493[0...9] Reset BICO interconnections to other drives / Reset BICO to drv
All objects Can be changed: T Calculated: - Access level: 3
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 15 15
