Figure 2-242 8948 – Master/slave (r0108.19 = 1)
- 8948 -
Function diagram
87654321
fp_8948_01_eng.vsd
DO: A_INF
SINAMICS S
17.11.06 V02.05.00
Active Infeed - Master / slave (r0108.19 = 1)
Multiplexer input 0
p3571[0]
Iq multi select
p3572
p3571[3]
p3571[2]
p3571[1]
r3573
Iq multi output
Y
X0
X1
X2
Iq_set
r3573
p3570
X3
[8940.5]
r3517
From master
PROFIdrive
Analogous
p0115[0] (250.00 µs)
1
[8950.1]
1
[8940.4]
r0070
Vdc_ist
Limit Uzk tension ribbon about-/ fallen
r3575.2
Vdc controller
0
1
0
1 An upper limit Uzk tension ribbon exceeded
r3575.0
A lower limit Uzk tension ribbon fallen.
r3575.1
Hysteresis lower tension limit
p3574[3]
Upper limit Uzk tension ribbon
p3574[0]
Lower limit Uzk tension ribbon
p3574[1]
Hysteresis upper tension limit.
p3574[2]
Multiplexer
