Parameters
List of parameters
1-892
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the limit of the circulating current controller output values.
The parameter is, depending on the phase, referred to the valve lockout times (p1828, p1829, p1830).
Description: Sets the limit of the circulating current controller output values.
The parameter is, depending on the phase, referred to the valve lockout times (p1828, p1829, p1830).
Description: For the particular Motor Module, the correction time must be added to the valve lockout time to be compensated for
phase U (p1828).
The corrective value is used to compensate variations/spread in the valve lockout times of Motor Modules for a par-
allel circuit configuration.
Dependency: Refer to: p1828
Description: For the particular Motor Module, the correction time must be added to the valve lockout time to be compensated for
phase V (p1829).
The corrective value is used to compensate variations/spread in the valve lockout times of Motor Modules for a par-
allel circuit configuration.
Dependency: Refer to: p1829
p7038 Infeed par_circuit circulating current control limit / I_circ limit
A_INF (Parallel),
S_INF (Parallel)
Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Modulation Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
1 [%] 100 [%] 100 [%]
p7038[0...n] Par_circuit circulating current control limit / I_circ limit
VECTOR (Parallel) Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: -
P-Group: Modulation Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
1 [%] 100 [%] 50 [%]
p7040[0...n] Par_circuit correction valve lockout time phase U / Comp t_lockout U
A_INF (Parallel),
S_INF (Parallel),
VECTOR (Parallel)
Can be changed: U, T Calculated: - Access level: 4
Data type: Floating Point Dynamic index: PDS, p0120 Func. diagram: -
P-Group: Modulation Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00 [µs] 1000000.00 [µs] 0.00 [µs]
p7042[0...n] Par_circuit correction valve lockout time phase V / Comp t_lockout V
A_INF (Parallel),
S_INF (Parallel),
VECTOR (Parallel)
Can be changed: U, T Calculated: - Access level: 4
Data type: Floating Point Dynamic index: PDS, p0120 Func. diagram: -
P-Group: Modulation Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00 [µs] 1000000.00 [µs] 0.00 [µs]
