List of faults and alarms
Faults and Alarms
3-1719
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
A34999 (F, N) VSM: Unknown alarm
Drive object: All objects
Reaction: NONE
Acknowledge: NONE
Cause: A fault occurred on the Voltage Sensing Module (VSM) an alarm has occurred that cannot be interpreted by the Con-
trol Unit firmware.
This can occur if the firmware on the module is more recent than the firmware on the Control Unit.
Alarm value (r2124, interpret decimal):
Alarm number.
If required, the significance of this new alarm can be read about in a more recent description of the Control Unit.
Remedy: - replace the firmware on the Voltage Sensing Module by an older firmware version (r0148).
- upgrade the firmware on the Control Unit (r0018).
Reaction upon F: A_INFEED: NONE (OFF1, OFF2)
SERVO: NONE (OFF1, OFF2, OFF3)
VECTOR: NONE (OFF1, OFF2, OFF3)
Acknowl. upon F: IMMEDIATELY (POWER ON)
Reaction upon N: NONE
Acknowl. upon N: NONE
F35000 TM54F: Sampling time invalid
Drive object: A_INF, B_INF, CU_LINK, DMC20, SERVO, S_INF, TB30, TM15, TM15DI_DO, TM17, TM31, TM41, TM54F_MA,
TM54F_SL, VECTOR
Reaction: NONE
Acknowledge: POWER ON
Cause: The set sampling time is invalid.
- not a multiple integer of the DP clock cycle.
Fault value (r0949, floating point):
Recommended valid sampling time.
Remedy: Adapt the sampling time (e.g. set the recommended valid sampling time).
See also: p10000 (SI sampling time)
F35001 TM54F: Parameter value invalid
Drive object: A_INF, B_INF, CU_LINK, DMC20, SERVO, S_INF, TB30, TM15, TM15DI_DO, TM17, TM31, TM41, TM54F_MA,
TM54F_SL, VECTOR
Reaction: NONE
Acknowledge: IMMEDIATELY (POWER ON)
Cause: The entered value is invalid.
Fault value (r0949, interpret decimal):
Parameter number with the invalid value.
Remedy: Correct the parameter value.
F35002 TM54F: Commissioning not possible
Drive object: A_INF, B_INF, CU_LINK, DMC20, SERVO, S_INF, TB30, TM15, TM15DI_DO, TM17, TM31, TM41, TM54F_MA,
TM54F_SL, VECTOR
Reaction: NONE
Acknowledge: IMMEDIATELY
Cause: The commissioning mode setting was rejected because for at least one drive belonging to the TM54F, the pulses
had not been canceled.
Fault value (r0949, interpret decimal):
Drive object number of the first drive found without pulse cancelation.
Remedy: Cancel the pulses for the drive specified in the fault value.
