Parameters
List of parameters
1-812
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Index: [0] = AO 0 (X482.5/X482.6)
[1] = AO 1 (X482.7/X482.8)
Description: Sets the offset for the analog outputs of terminal module 31 (TM31).
The offset is added to the output signal after the normalization characteristic.
Index: [0] = AO 0 (X522.1, X522.2, X522.3)
[1] = AO 1 (X522.4, X522.5, X522.6)
Dependency: The units of this parameter (V or mA) depend on the analog input type.
Refer to: r4076, p4076
Note: This means, for example, the offset of a downstream isolating amplifier can be compensated.
Description: Sets the signal source for terminal DI/DO 16 (X522.2) of terminal module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.16 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 17 (X522.3) of terminal module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.17 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 18 (X522.4) of terminal module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.18 = 1).
DI/DO: Bidirectional Digital Input/Output
p4083[0...1] TM31 analog outputs, offset / TM31 AO offset
TM31 Can be changed: U, T Calculated: - Access level: 1
Data type: Floating Point Dynamic index: - Func. diagram: 9572
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
-20.000 20.000 0.000
p4086 BI: TM15DI/DO signal source for terminal DI/DO 16 / TM15D S_srcDI/DO16
TM15DI_DO Can be changed: U, T Calculated: - Access level: 1
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 9402
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
p4087 BI: TM15DI/DO signal source for terminal DI/DO 17 / TM15D S_srcDI/DO17
TM15DI_DO Can be changed: U, T Calculated: - Access level: 1
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 9402
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
p4088 BI: TM15DI/DO signal source for terminal DI/DO 18 / TM15D S_srcDI/DO18
TM15DI_DO Can be changed: U, T Calculated: - Access level: 1
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 9402
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
