List of parameters

Parameters

1-565

SINAMICS S List Manual (LH1), 07/2007

Note: IF1: Interface 1

Description: Binector output for bit-serial onward interconnection of a PZD word received from the PROFIBUS/PROFINET mas-

ter .

The PZD is selected via p2099[0].

Dependency: Refer to: p2099

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 On Off -

01 Bit 1 On Off -

02 Bit 2 On Off -

03 Bit 3 On Off -

04 Bit 4 On Off -

05 Bit 5 On Off -

06 Bit 6 On Off -

07 Bit 7 On Off -

08 Bit 8 On Off -

09 Bit 9 On Off -

10 Bit 10 On Off -

11 Bit 11 On Off -

12 Bit 12 On Off -

13 Bit 13 On Off -

14 Bit 14 On Off -

15 Bit 15 On Off -

r2094.0...15 BO: Connector-binector converter binector output / Con/bin outp

A_INF, B_INF,

CU_CX32, CU_S,

SERVO, S_INF,

TB30, TM15DI_DO,

TM31, TM41, VEC-

TOR

Can be changed: - Calculated: - Access level: 3

Data type: Unsigned16 Dynamic index: - Func. diagram: 2460

P-Group: Communications Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -
