Siemens SINAMICS S Series - p4044 BI: TM15 DI;DO signal source for terminal DI;DO 14; TM15 D S_srcDI;DO14; p4045 BI: TM15 DI;DO signal source for terminal DI;DO 15; TM15 D S_srcDI;DO15; p4046 TM31 digital outputs, limit current; TM31 DO limit curr; r4047 TB30 digital outputs status; TB30 DO status

Parameters
List of parameters
1-788
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the signal source for terminal DI/DO 14 (X521.8) of terminal module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.14 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the signal source for terminal DI/DO 15 (X521.9) of terminal module 15 (TM15).
Note: Prerequisite: The DI/DO must be set as an output (p4028.15 = 1).
DI/DO: Bidirectional Digital Input/Output
Description: Sets the limit for the total output voltage of terminals X541.1, X541.2, X541.3 and X541.4 (DI/DO 8 ... 11) of termi-
nal module 31 (TM31).
Values: 0: 0.1 A total current limit DI/DO 8 ... 11
1: 1.0 A total current limit DI/DO 8 ... 11
Dependency: Refer to: p4028
Warning: Since the sum of the output currents at terminals X541.1, X541.2, X541.3 and X541.4 is limited, an overcurrent or
short circuit at one output terminal can cause a dip in the signal at the other terminals.
Description: Displays the status of the digital outputs of the Terminal Board 30 (TB30).
p4044 BI: TM15DI/DO signal source for terminal DI/DO 14 / TM15D S_srcDI/DO14
TM15DI_DO Can be changed: U, T Calculated: - Access level: 1
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 9401
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
p4045 BI: TM15DI/DO signal source for terminal DI/DO 15 / TM15D S_srcDI/DO15
TM15DI_DO Can be changed: U, T Calculated: - Access level: 1
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 9401
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
p4046 TM31 digital outputs, limit current / TM31 DO limit curr
TM31 Can be changed: T Calculated: - Access level: 2
Data type: Integer16 Dynamic index: - Func. diagram: 9560
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 1 0
r4047 TB30 digital outputs status / TB30 DO status
TB30 Can be changed: - Calculated: - Access level: 1
Data type: Unsigned32 Dynamic index: - Func. diagram: 9102
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 DO 0 (X481.5) High Low -
01 DO 1 (X481.6) High Low -
02 DO 2 (X481.7) High Low -
03 DO 3 (X481.8) High Low -
