List of parameters
Parameters
1-45
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the smoothed actual value of the motor speed.
Dependency: Refer to: r0063
Note: Smoothing time constant = 100 ms
The signal is not suitable as process quantity and may only be used as display quantity.
The value displayed in r0021 is the smoothed value of r0063.
Description: Displays the smoothed actual value of the motor velocity.
Dependency: Refer to: r0063
Note: Smoothing time constant = 100 ms
The signal is not suitable as process quantity and may only be used as display quantity.
The value displayed in r0021 is the smoothed value of r0063.
Description: Displays the smoothed actual value of motor speed. r0022 is identical to r0021, however, it always has units of rpm
and contrary to r0021 cannot be changed over.
Dependency: Refer to: r0063
Note: Smoothing time constant = 100 ms
The signal is not suitable as process quantity and may only be used as display quantity.
The value displayed in r0022 is the smoothed value of r0063.
r0021 CO: Actual speed smoothed / n_ist smooth
SERVO, VECTOR Can be changed: - Calculated: - Access level: 2
Data type: Floating Point Dynamic index: - Func. diagram: 1580, 1680,
4710, 6799
P-Group: Displays, signals Units group: 3_1 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [RPM] - [RPM] - [RPM]
r0021 CO: Actual velocity smoothed / v_act smooth
SERVO (Lin) Can be changed: - Calculated: - Access level: 2
Data type: Floating Point Dynamic index: - Func. diagram: 1580, 1680,
4710, 6799
P-Group: Displays, signals Units group: 4_1 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [m/min] - [m/min] - [m/min]
r0022 Speed actual value rpm smoothed / n_ist rpm smooth
SERVO, VECTOR Can be changed: - Calculated: - Access level: 2
Data type: Floating Point Dynamic index: - Func. diagram: 1580, 1680,
4710, 6799
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [RPM] - [RPM] - [RPM]
