Siemens SINAMICS S Series User Manual

List of parameters
Parameters
1-935
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
[64] = Fault 8/ drive 7
[65] = Number of faults drive 8
[66] = Fault 1/ drive 8
[67] = Fault 2/ drive 8
[68] = Fault 3/ drive 8
[69] = Fault 4/ drive 8
[70] = Fault 5/ drive 8
[71] = Fault 6/ drive 8
[72] = Fault 7/ drive 8
[73] = Fault 8/ drive 8
[74] = Number of faults Control Unit
[75] = Fault 1/Control Unit
[76] = Fault 2/Control Unit
[77] = Fault 3/Control Unit
[78] = Fault 4/Control Unit
[79] = Fault 5/Control Unit
[80] = Fault 6/Control Unit
[81] = Fault 7/Control Unit
[82] = Fault 8/Control Unit
Note: Faults, whose causes have been removed and only have to be acknowledged are no longer contained in the pre-
defined error field. These faults are still contained in parameter p0945.
Description: Display or setting of the CANopen Node ID.
The Node ID can be set as follows:
1) Using the DIP switch power-up the Control Unit.
--> p8620 can then only be read and displays the selected Node ID.
--> A change only becomes effective after a POWER ON.
--> CANopen Node ID and PROFIBUS address are identical.
2) Using p8620
--> only if all of the DIP switches - from S1 to S7 - are either set to ON or OFF.
--> the Node ID is set as standard to 126.
--> A change only becomes effective after save and POWER ON.
Note: Every node ID change only becomes effective after a POWER ON.
It is only possible to independently set CANopen node ID and the PROFIBUS address using p0918 and p8620 (pre-
requisite: For DIP switches, all of the switches from S1 to S7 are either set to ON or OFF).
Description: Setting the baud rate for the CAN bus.
The appropriate bit timings are selected that are defined in p8623 in the associated sub-index.
Values: 0: 1 Mbit/s
1: 800 kbit/s
2: 500 kbit/s
3: 250 kbit/s
p8620 CBC node ID / Node ID
CU_S (CAN) Can be changed: T Calculated: - Access level: 2
Data type: Unsigned8 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
1 126 126
p8622 CBC baud rate / Baud rate
CU_S (CAN) Can be changed: T Calculated: - Access level: 3
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 7 6
