Parameters
List of parameters
1-980
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the velocity limit for the SSM feedback signal to detect standstill.
When this limit value is fallen below, the signal "SSM feedback signal active" is set.
Dependency: Refer to: p9546
Caution: The function "Safe Acceleration Monitor" (SBR) is switched-out after the selected threshold value is fallen below.
Notice: This parameter is overwritten by the copy function of the safety functions integrated in the drive.
Note: A change only becomes effective after a POWER ON.
SBR: Safe Acceleration Monitor
SSM: Safe Speed Monitor (safety-relevant feedback signal from the velocity monitoring)
Description: Sets the velocity limit for the SSM feedback signal to detect standstill.
When this limit value is fallen below, the signal "SSM feedback signal active" is set.
Dependency: Refer to: p9546
Caution: The function "Safe Acceleration Monitor" (SBR) is switched-out after the selected threshold value is fallen below.
Notice: This parameter is overwritten by the copy function of the safety functions integrated in the drive.
Note: A change only becomes effective after a POWER ON.
SBR: Safe Acceleration Monitor
SSM: Safe Speed Monitor (safety-relevant feedback signal from the velocity monitoring)
Description: Sets the velocity tolerance for the "Safe Acceleration Monitor".
Dependency: Refer to: p9548
Refer to: C01706
Notice: This parameter is overwritten by the copy function of the safety functions integrated in the drive.
Note: A change only becomes effective after a POWER ON.
SBR: Safe Acceleration Monitor
p9346 SI motion SSM velocity limit (Motor Module) / SI Mtn SSM v_limMM
SERVO, VECTOR Can be changed: C2 Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00 [mm/min] 1000000.00 [mm/min] 20.00 [mm/min]
p9346 SI motion SSM velocity limit (Motor Module) / SI Mtn SSM v_limMM
SERVO (Safety rot),
VECTOR (Safety rot)
Can be changed: C2 Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00 [RPM] 1000000.00 [RPM] 20.00 [RPM]
p9348 SI motion SBR actual velocity tolerance (Motor Module) / SI Mtn SBR Tol MM
SERVO, VECTOR Can be changed: C2 Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00 [mm/min] 120000.00 [mm/min] 300.00 [mm/min]
