Parameters

List of parameters

1-830

SINAMICS S List Manual (LH1), 07/2007

Description: Sets the smoothing time constant for digital input 0 ... 15 of terminal module 17 (TM17).

Note: DI/DO: Bidirectional Digital Input/Output

DI: Digital input

Description: Sets as absolute or relative timing with bit 0 ... 15 for digital output 0 ... 15 of terminal module 17 (TM17).

Note: DI/DO: Bidirectional Digital Input/Output

DO: Digital Output

p4221 TM17 smoothing time constant, digital input 0 ... 15 / TM17 smooth DI

TM17 Can be changed: U, T Calculated: - Access level: 2

Data type: Unsigned32 Dynamic index: - Func. diagram: -

P-Group: Commands Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - 0000 bin

Bit field: Bit Signal name 1 signal 0 signal FP

00 DI/DO 0 (X520.2) Smoothing 1 µs Smoothing 125 µs -

01 DI/DO 1 (X520.3) Smoothing 1 µs Smoothing 125 µs -

02 DI/DO 2 (X520.5) Smoothing 1 µs Smoothing 125 µs -

03 DI/DO 3 (X520.6) Smoothing 1 µs Smoothing 125 µs -

04 DI/DO 4 (X520.8) Smoothing 1 µs Smoothing 125 µs -

05 DI/DO 5 (X520.9) Smoothing 1 µs Smoothing 125 µs -

06 DI/DO 6 (X521.2) Smoothing 1 µs Smoothing 125 µs -

07 DI/DO 7 (X521.3) Smoothing 1 µs Smoothing 125 µs -

08 DI/DO 8 (X521.8) Smoothing 1 µs Smoothing 125 µs -

09 DI/DO 9 (X521.9) Smoothing 1 µs Smoothing 125 µs -

10 DI/DO 10 (X522.2) Smoothing 1 µs Smoothing 125 µs -

11 DI/DO 11 (X522.3) Smoothing 1 µs Smoothing 125 µs -

12 DI/DO 12 (X522.5) Smoothing 1 µs Smoothing 125 µs -

13 DI/DO 13 (X522.6) Smoothing 1 µs Smoothing 125 µs -

14 DI/DO 14 (X522.8) Smoothing 1 µs Smoothing 125 µs -

15 DI/DO 15 (X522.9) Smoothing 1 µs Smoothing 125 µs -

p4222 TM17 time absolute/relative digital output 0 ... 15 / TM17 abs/rel 0-15

TM17 Can be changed: T Calculated: - Access level: 2

Data type: Unsigned32 Dynamic index: - Func. diagram: -

P-Group: Commands Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - 0000 bin

Bit field: Bit Signal name 1 signal 0 signal FP

00 DI/DO 0 (X520.2) Relative time Absolute time -

01 DI/DO 1 (X520.3) Relative time Absolute time -

02 DI/DO 2 (X520.5) Relative time Absolute time -

03 DI/DO 3 (X520.6) Relative time Absolute time -

04 DI/DO 4 (X520.8) Relative time Absolute time -

05 DI/DO 5 (X520.9) Relative time Absolute time -

06 DI/DO 6 (X521.2) Relative time Absolute time -

07 DI/DO 7 (X521.3) Relative time Absolute time -

08 DI/DO 8 (X521.8) Relative time Absolute time -

09 DI/DO 9 (X521.9) Relative time Absolute time -

10 DI/DO 10 (X522.2) Relative time Absolute time -

11 DI/DO 11 (X522.3) Relative time Absolute time -

12 DI/DO 12 (X522.5) Relative time Absolute time -

13 DI/DO 13 (X522.6) Relative time Absolute time -

14 DI/DO 14 (X522.8) Relative time Absolute time -

15 DI/DO 15 (X522.9) Relative time Absolute time -
