Siemens SINAMICS S Series - r1651 CO: Torque setpoint, function generator; M_set FG; r1651 CO: Force setpoint, function generator; F_set FG; p1653[0...n] Current setpoint torque-generating minimum smoothing time; Isq_s T_smth_min; p1654[0...n] Curr. setpoint torque-gen. smoothing time field weakening range; Isq_s T_smth FW

List of parameters
Parameters
1-461
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the torque setpoint of the function generator.
Description: Displays the force setpoint of the function generator.
Description: Sets the minimum smoothing time constant for the setpoint of the torque-generating current components.
Description: Sets the smoothing time constant for the setpoint of the torque-generating current components.
Note: The smoothing time does not become effective until the field-weakening range is reached.
Description: Sets the signal source for tuning the natural frequency of the current setpoint filter.
Index: [0] = Filter 1
[1] = Filter 2
r1651 CO: Torque setpoint, function generator / M_set FG
SERVO, VECTOR
(n/M)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Closed-loop control Units group: 7_1 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [Nm] - [Nm] - [Nm]
r1651 CO: Force setpoint, function generator / F_set FG
SERVO (Lin) Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Closed-loop control Units group: 8_1 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [N] - [N] - [N]
p1653[0...n] Current setpoint torque-generating minimum smoothing time / Isq_s T_smth_min
VECTOR (n/M) Can be changed: U, T Calculated: - Access level: 4
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: -
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: PEM, REL Expert list: 1
Min Max Factory setting
0.1 [ms] 20.0 [ms] 0.1 [ms]
p1654[0...n] Curr. setpoint torque-gen. smoothing time field weakening range / Isq_s T_smth FW
VECTOR (n/M) Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 4
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: 6710
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: PEM, REL Expert list: 1
Min Max Factory setting
0.1 [ms] 50.0 [ms] 4.8 [ms]
p1655[0...1] CI: Current setpoint filter natural frequency tuning / I_set_filt f_n
VECTOR (n/M) Can be changed: U, T Calculated: - Access level: 3
Data type: Unsigned32 / FloatingPoint32 Dynamic index: - Func. diagram: 6710
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
- - 1
