Faults and Alarms
List of faults and alarms
3-1630
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
See also: p9552 (SI motion transition time STOP C to SOS (SBH) (Control Unit))
Remedy: - remove the cause of the fault at the control.
- carry out a diagnostics routine for message C30714.
This message can only be acknowledged via the Terminal Module 54F (TM54F) or PROFIsafe.
Note:
SI: Safety Integrated
SOS: Safe Operating Stop / SBH: Safe operating stop
C30709 SI Motion MM: STOP D initiated
Drive object: SERVO, VECTOR
Reaction: NONE
Acknowledge: IMMEDIATELY (POWER ON)
Cause: The drive is stopped via a STOP D (braking along the path).
"Safe Operating Stop" (SOS) is activated after the parameterized timer stage has expired.
Possible causes:
- stop request from the Control Unit.
- subsequent response to the message C30714 "SI Motion: Safely limited speed exceeded".
See also: p9353 (SI Motion transition time STOP D to SOS (Motor Module)), p9553 (SI motion transition time STOP
D to SOS (SBH) (Control Unit))
Remedy: - remove the cause of the fault at the control.
- carry out a diagnostics routine for message C30714.
This message can only be acknowledged via the Terminal Module 54F (TM54F) or PROFIsafe.
Note:
SI: Safety Integrated
SOS: Safe Operating Stop / SBH: Safe operating stop
C30711 SI MM MM: Defect in a monitoring channel
Drive object: SERVO, VECTOR
Reaction: NONE
Acknowledge: IMMEDIATELY (POWER ON)
Cause: When cross-checking and comparing the two monitoring channels, the drive detected a difference between the input
data or results of the monitoring functions and initiated a STOP F. One of the monitoring functions no longer reliably
functions - i.e. safe operation is no longer possible.
If at least one monitoring function is active, then after the parameterized timer stage has expired, the message
C30701 "SI Motion: STOP B initiated" is output. The alarm is output with message value 1031 when the Sensor Mod-
ule hardware is replaced.
Message value (r9749, interpret decimal):
0 ... 999: Number of the cross-checked data that resulted in this fault.
0: Stop request from the other monitoring channel.
1: Status image of monitoring functions SOS, SLS or SLP (result list 1) (r9710[0], r9710[1]).
2: Status image of monitoring function SCA or n < nx (result list 2) (r9711[0], r9711[1]).
3: Position actual value.
4: Error when synchronizing the crosswise data comparison between the two channels.
5: Function enable signals (p9501, p9301).
6: Limit value for SLS1 (p9531[0], p9331[0]).
7: Limit value for SLS2 (p9531[1], p9331[1]).
8: Limit value for SLS3 (p9531[2], p9331[2]).
9: Limit value for SLS4 (p9531[3], p9331[3]).
10: Standstill tol. (p9530, p9330).
31: Pos. tol. (p9542, p9342).
33: Time, velocity changeover (p9551, p9351).
35: Delay time, pulse canc. (p9556, p9356).
36: Checking time, pulse canc. (p9557, p9357).
37: Trans. time, STOP C to SOS (p9552, p9352).
38: Trans. time STOP D to SOS (p9553, p9353).
40: Stop response for SLS.
42: Shutdown speed, pulse canc. (p9560, p9360).
43: Memory test, stop response (STOP A).
44: Position actual value + limit value SLS1 / safety monitoring clock cycle.
45: Pos. act. val. - limit value SLS1 / safety monitoring clock cycle.
46: Pos. act. val. + limit value SLS2 / safety monitoring clock cycle.
