Parameters
List of parameters
1-684
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the position difference before the load gearbox between powering-down and powering-up.
Note: The increments are displayed in the same format as for r0483/r2723.
If the measuring gearbox of the motor encoder is not activated, the position difference should be read in encoder
increments.
If the measuring gearbox of the motor encoder is activated, the position difference is converted using the measuring
gearbox factor.
Description: Sets a fixed percentage.
Dependency: Refer to: p2901, p2930
Notice: A BICO interconnection to a parameter that belongs to a drive objects always acts on the effective data set.
Note: The value can be used to interconnect a scaling function (e.g. scaling of the main setpoint)
Description: Sets a fixed percentage.
Dependency: Refer to: p2900, p2930
Notice: A BICO interconnection to a parameter that belongs to a drive objects always acts on the effective data set.
Note: The value can be used to interconnect a scaling function (e.g. scaling of the supplementary setpoint)
Description: Signal sources for frequently used percentage values.
Index: [0] = Fixed value +0 %
[1] = Fixed value +5 %
[2] = Fixed value +10 %
[3] = Fixed value +20 %
[4] = Fixed value +50 %
r2724[0...n] CO: Load gearbox position difference / Load grbx pos diff
SERVO, VECTOR Can be changed: - Calculated: - Access level: 1
Data type: Integer32 Dynamic index: DDS, p0180 Func. diagram: -
P-Group: Encoder Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
p2900[0...n] CO: Fixed value 1 [%] / Fixed value 1 [%]
SERVO, VECTOR Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: 1021
P-Group: Free function blocks Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
-10000.00 [%] 10000.00 [%] 0.00 [%]
p2901[0...n] CO: Fixed value 2 [%] / Fixed value 2 [%]
SERVO, VECTOR Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: 1021
P-Group: Free function blocks Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
-10000.00 [%] 10000.00 [%] 0.00 [%]
r2902[0...14] CO: Fixed values [%] / Fixed values [%]
SERVO, VECTOR Can be changed: - Calculated: - Access level: 1
Data type: Floating Point Dynamic index: - Func. diagram: 1021
P-Group: Free function blocks Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [%] - [%] - [%]
