Page #711 background image
List of parameters
Parameters
1-711
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the setpoint for the DC link voltage.
Dependency: Refer to: p0210, p0280, p3400, r3508, p3511
Warning: Before increasing the voltage limit for pulsed operation of a controlled booksize infeed with line supply voltages
p0210 > 415 V it should be checked whether the motors, connected to the DC link, are specified for the higher
motor voltages.
The warning information associated with p0210 must be carefully observed.
Note: When the Smart Mode is activated (p3400.0 = 1) the DC link voltage is not regulated, i.e. the value entered here is
in this case not effective.
The permissible range of the DC link voltage depends on the parameterized unit supply voltage (p0210) and the
permissible, maximum continuous DC link voltage (p0280).
In voltage-controlled operation (p3400.0 = 0) the following applies:
p3510 >= 1.42 * p0210 and
p3510 <= p3508 * p0210 and
p3510 <= p0280.
In the Smart Mode (p3400.0 = 1) the following applies:
The setpoint p3510 for the DC link voltage control is inactive. In order to permit an adapted display, deviating from
voltage-controlled operation, the lower limit p3510 is >= 1.2 * p0210.
Description: Sets the signal source for the supplementary setpoint for the DC link voltage.
Dependency: Refer to: p3510
Description: Sets the signal source for inhibiting the voltage-controlled mode of the infeed.
Dependency: Refer to: p3400, r3405
Notice: The DC link voltage must be controlled by a different component at the DC link; otherwise this results in an overvolt-
age or undervoltage condition.
Note: The current controller remains active and can be controlled by means of its setpoint inputs (p3515, p3610).
This binector input is used to change over between master (0 signal) and slave (1 signal) operation and vice versa.
p3510 Infeed DC link voltage setpoint / INF Vdc setp
A_INF Can be changed: U, T Calculated: - Access level: 2
Data type: Floating Point Dynamic index: - Func. diagram: 1774, 8940
P-Group: Closed-loop control Units group: 5_2 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
100.00 [V] 1600.00 [V] 600.00 [V]
p3511 CI: Infeed DC link voltage supplementary setpoint / INF Vdc Z_set
A_INF Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / FloatingPoint32 Dynamic index: - Func. diagram: 8940
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
p3513 BI: Inhibit voltage-controlled operation / Inhib V_ctrl mode
A_INF Can be changed: U, T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
