Figure 2-81 2505 – Control word setpoint channel
- 2505 -
Function diagram
87654321
fp_2505_51_eng.vsd
DO: SERVO, VECTOR, VECTORGL, VECTORMV
SINAMICS
31.05.06 V02.05.00
Internal control/status words - Control word, setpoint channel
11
12
13
14
15
1 = Fixed setpoint, bit 0
Control word, setpoint channel
1 = Fixed setpoint, bit 1
1 = Fixed setpoint, bit 2
1 = Fixed setpoint, bit 3
Reserved
1 = Inhibit negative direction of rotation
1 = Inhibit positive direction of rotation
Reserved
Reserved
Reserved
Reserved
1 = Dir of rot reversal
Reserved
1 = Motorized potentiometer, raise
1 = Bypass ramp-function generator
1 = Motorized potentiometer, lower
p1020[C]
(0)
Fixed setpoint selection, bit 0
p1023[C]
(0)
Fixed setpoint selection, bit 3
p1111[C]
(0)
p1036[C]
(0)
Motorized potentiometer, lower
p1035[C]
(0)
Motorized potentiometer, raise
PROFIdrive bit
9
10
8
7
6
5
4
3
2
1
0
Bit No.
p0115[3]
r1198.3
r1198.5
r1198.6
r1198.11
r1198.13
r1198.14
p1022[C]
(0)
Fixed setpoint selection, bit 2
p1021[C]
(0)
Fixed setpoint selection, bit 1
r1198
STW setpoint channel
r1198.2
r1198.1
r1198.0
p1113[C]
(0)
Direction of rotation reversal
To the setpoint channel [3060.1] [3070.3]r1198.15
p1122[C]
(0)
Bypass RFG
To fixed speed setpoints [3010.2]
To fixed speed setpoints [3010.2]
To fixed speed setpoints [3010.2]
To fixed speed setpoints [3010.2]
To direction of rotation limiting and
direction of rotation reversal [3040.3]
To direction of rotation limiting and
direction of rotation reversal [3040.5]
To the motorized potentiometer [3020.1]
To the motorized potentiometer [3020.1]
To direction of rotation limiting and
direction of rotation reversal [3040.2]
p1110[C]
(0)
