Siemens SINAMICS S Series - r4363 TM17 edge times digital input 13; TM17 edge_t DI 13; r4363 TM15 edge times digital input 13; TM15 edge_t DI 13; r4364 TM17 edge times digital input 14; TM17 edge_t DI 14; r4364 TM15 edge times digital input 14; TM15 edge_t DI 14

Parameters
List of parameters
1-852
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the time when detecting the 1st and 2nd edge for digital input 13 of terminal module 17 (TM17).
The two times are specified as 16 bit values with a resolution of 0.25 µs.
Note: DI: Digital input
Description: Displays the time when detecting the 1st and 2nd edge for digital input 13 of terminal module 15 (TM15).
The two times are specified as 8 bit values with a resolution of 64 µs.
Note: DI: Digital input
Description: Displays the time when detecting the 1st and 2nd edge for digital input 14 of terminal module 17 (TM17).
The two times are specified as 16 bit values with a resolution of 0.25 µs.
Note: DI: Digital input
Description: Displays the time when detecting the 1st and 2nd edge for digital input 14 of terminal module 15 (TM15).
The two times are specified as 8 bit values with a resolution of 64 µs.
Note: DI: Digital input
r4363 TM17 edge times digital input 13 / TM17 edge_t DI 13
TM17 Can be changed: - Calculated: - Access level: 3
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r4363 TM15 edge times digital input 13 / TM15 edge_t DI 13
TM15 Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r4364 TM17 edge times digital input 14 / TM17 edge_t DI 14
TM17 Can be changed: - Calculated: - Access level: 3
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r4364 TM15 edge times digital input 14 / TM15 edge_t DI 14
TM15 Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
