List of parameters
Parameters
1-77
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
For SERVO, the following applies:
The calculation of the torque utilization depends on the selected smoothing time constant (p0045).
Description: Displays the force utilization as a percentage.
The force utilization is obtained from the required smoothed force referred to the force limit.
Dependency: Refer to: r0033
Note: The force utilization is available smoothed (r0033) and unsmoothed (r0081).
The calculation of the force utilization depends on the selected smoothing time constant (p0045).
Description: Displays the instantaneous active power.
Dependency: Refer to: r0032
Note: The active power is available smoothed (r0032) and unsmoothed (r0082).
Description: Displays the instantaneous active power.
Index: [0] = Unsmoothed
[1] = Smoothed with p0045
[2] = Power drawn
Dependency: Refer to: r0032
Note: The active power is available smoothed (r0032 with 100 ms, r0082[1] with p0045) and unsmoothed (r0082[0]).
Description: Displays the instantaneous active power.
Index: [0] = Unsmoothed
[1] = Smoothed with p0045
r0081 CO: Force utilization / F_utilization
SERVO (Lin) Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 8012
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [%] - [%] - [%]
r0082 CO: Active power actual value / P_act
A_INF, B_INF,
S_INF
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 8750, 8850,
8950
P-Group: Displays, signals Units group: 14_7 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [kW] - [kW] - [kW]
r0082[0...2] CO: Active power actual value / P_act
SERVO Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 5730
P-Group: Displays, signals Units group: 14_5 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [kW] - [kW] - [kW]
r0082[0...2] CO: Active power actual value / P_act
VECTOR Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 6714, 6799
P-Group: Displays, signals Units group: 14_5 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [kW] - [kW] - [kW]
