Parameters

List of parameters

1-960

SINAMICS S List Manual (LH1), 07/2007

Description: Selects the PZD (actual values) to be sent via interface 2 in the word format.

Index: [0] = PZD 1

[1] = PZD 2

[2] = PZD 3

[3] = PZD 4

[4] = PZD 5

[5] = PZD 6

[6] = PZD 7

[7] = PZD 8

[8] = PZD 9

[9] = PZD 10

[10] = PZD 11

[11] = PZD 12

[12] = PZD 13

[13] = PZD 14

[14] = PZD 15

[15] = PZD 16

Dependency: Refer to: p8861

Note: IF2: Interface 2

Description: Displays the sent PZD (actual values) sent via interface 2.

Index: [0] = PZD 1

[1] = PZD 2

[2] = PZD 3

[3] = PZD 4

[4] = PZD 5

[5] = PZD 6

[6] = PZD 7

[7] = PZD 8

p8851[0...15] CI: IF2 PZD send word / IF2 PZD send word

SERVO, VECTOR Can be changed: U, T Calculated: - Access level: 3

Data type: Unsigned32 / Integer16 Dynamic index: - Func. diagram: 2487, 9208

P-Group: Communications Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - 0

r8853[0...7] IF2 diagnostics PZD send / IF2 diag PZD send

A_INF, B_INF,

S_INF

Can be changed: - Calculated: - Access level: 3

Data type: Unsigned16 Dynamic index: - Func. diagram: 2493

P-Group: Communications Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 On Off -

01 Bit 1 On Off -

02 Bit 2 On Off -

03 Bit 3 On Off -

04 Bit 4 On Off -

05 Bit 5 On Off -

06 Bit 6 On Off -

07 Bit 7 On Off -

08 Bit 8 On Off -

09 Bit 9 On Off -

10 Bit 10 On Off -

11 Bit 11 On Off -

12 Bit 12 On Off -
