List for motor code/encoder code

Appendix

A-1775

SINAMICS S List Manual (LH1), 07/2007

A.2.2 Encoder code

1FK6 encoders

1FK7 encoders

Table A-5 Encoder code for 1FK6 encoders

Order number Encoder code (p0400) Comments

1FK6xxx-xxxxx-xAxx 2001 -

1FK6xxx-xxxxx-xExx 2051 -

1FK6xxx-xxxxx-xGxx 2052 -

1FK6xxx-xxxxx-xHxx 2053 -

1FK6xxx-xxxxx-xJxx 2054 -

1FK6xxx-xxxxx-xSxx 1002

1003

1004

4p (2-speed)

6p (3-speed)

8p (4-speed)

The pole number of the resolver cor-

responds to the pole number of the

motor (see catalog).

1FK6xxx-xxxxx-xTxx 1001 -

Table A-6 Encoder code for 1FK7 encoders

Order number Encoder code (p0400) Comments

1FK7xxx-xxxxx-xAxx 2001 -

1FK7xxx-xxxxx-xExx 2051 -

1FK7xxx-xxxxx-xGxx 2052 -

1FK7xxx-xxxxx-xHxx 2053 -

1FK7xxx-xxxxx-xJxx 2054 -

1FK7xxx-xxxxx-xSxx 1002
