List of parameters
Parameters
1-251
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the signal source for the 2nd OC/OFF3.
The AND logic operation of the 1st OC/OFF3 and 2nd OC/OFF3 results in control word 1, bit 2 (OC/OFF3).
Note: Bit 2 = 0: OFF3 (braking along the OFF3 ramp (p1135), then pulse cancelation and power-on inhibit)
Bit 2 = 1: No OFF3 (enable is possible)
OC: Operating condition
Description: Sets the signal source for control word 1 bit 3 (enable operation)
Caution: When "master control from PC" is activated, this binector input is ineffective.
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: Bit 3 = 0: Inhibit operation (cancel pulses)
Bit 3 = 1: Enable operation (pulses can be enabled)
Description: Sets the signal source for control word 1 bit 3 (enable operation)
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: Bit 3 = 0: Inhibit operation (cancel pulses)
Bit 3 = 1: Enable operation (pulses can be enabled)
Description: Sets the signal source for control word 1 bit 10 (master control by PLC).
p0849[0...n] BI: 2. OFF3 / 2. OFF3
SERVO, VECTOR Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dynamic index: CDS, p0170 Func. diagram: 2501
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 1
p0852[0...n] BI: Enable operation / Enable operation
A_INF, SERVO,
S_INF, VECTOR
Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dynamic index: CDS, p0170 Func. diagram: 2501, 8820,
8920
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 1
p0852 BI: Enable operation / Enable operation
TM41 Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 1
p0854[0...n] BI: Master ctrl by PLC / Master ctrl by PLC
A_INF, B_INF,
SERVO, S_INF,
VECTOR
Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / Binary Dynamic index: CDS, p0170 Func. diagram: 2501, 8720,
8820, 8920
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 1
