List of parameters
Parameters
1-925
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the signal source for bitwise data transfer.
These signals are transferred to another Control Unit and are located in BO: r8511.0 ... 15 for further interconnec-
tion.
Index: [0] = Send signal to BO: r8511.0
[1] = Send signal to BO: r8511.1
[2] = Send signal to BO: r8511.2
[3] = Send signal to BO: r8511.3
[4] = Send signal to BO: r8511.4
[5] = Send signal to BO: r8511.5
[6] = Send signal to BO: r8511.6
[7] = Send signal to BO: r8511.7
[8] = Send signal to BO: r8511.8
[9] = Send signal to BO: r8511.9
[10] = Send signal to BO: r8511.10
[11] = Send signal to BO: r8511.11
[12] = Send signal to BO: r8511.12
[13] = Send signal to BO: r8511.13
[14] = Send signal to BO: r8511.14
[15] = Send signal to BO: r8511.15
Dependency: Refer to: r8511
Description: Sets the signal source for the wordwise data transfer (process signal).
This signal value is transferred to another Control Unit and is located at CO: r8512 for further interconnection.
Dependency: Refer to: r8512
p8501[0...15] BI: Data transfer 1 bitwise / Transfer 1 bit
CU_LINK Can be changed: U, T Calculated: - Access level: 2
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 2211
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - [0] 722.0
[1] 722.1
[2] 722.2
[3] 722.3
[4] 722.4
[5] 722.5
[6] 722.6
[7] 722.7
[8] 722.8
[9] 722.9
[10] 722.10
[11] 722.11
[12] 722.12
[13] 722.13
[14] 722.14
[15] 722.15
p8502 CI: Data transfer 0 wordwise / Transfer 0 word
CU_CX32, CU_LINK Can be changed: U, T Calculated: - Access level: 2
Data type: Unsigned32 / FloatingPoint32 Dynamic index: - Func. diagram: 2211
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
