Parameters

List of parameters

1-260

SINAMICS S List Manual (LH1), 07/2007

Note: Re bit 12:

The feedback signal of a line contactor (auxiliary contact) can be interconnected via BI: p0860.

Description: Displays the status word of the infeed sequence control.

Note: Re bit 0, 1, 2, 4, 6, 9:

For PROFIdrive, these signals are used for status word 1.

Description: Displays the status word of the sequence control.

Bit field: Bit Signal name 1 signal 0 signal FP

00 Ready to power up Yes No -

01 Ready Yes No -

02 Operation enabled Yes No -

04 No OFF2 active OFF2 inactive OFF2 active -

06 Power-on inhibit Yes No -

09 Control requested Yes No -

11 Pre-charging compl Yes No -

12 Line contactor closed Yes No 8934

r0899.0...12 CO/BO: Status word sequence control infeed / ZSW seq_ctrl INF

B_INF Can be changed: - Calculated: - Access level: 2

Data type: Unsigned16 Dynamic index: - Func. diagram: 8726

P-Group: Displays, signals Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Ready to power up Yes No -

01 Ready Yes No -

02 Operation enabled Yes No -

04 No OFF2 active OFF2 inactive OFF2 active -

06 Power-on inhibit Yes No -

09 Control requested Yes No -

11 Pre-charging compl Yes No -

12 Line contactor closed Yes No -

r0899.0...15 CO/BO: Status word sequence control / ZSW seq_ctrl

SERVO, VECTOR Can be changed: - Calculated: - Access level: 2

Data type: Unsigned16 Dynamic index: - Func. diagram: 1530, 2503

P-Group: Displays, signals Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Ready to power up Yes No -

01 Ready Yes No -

02 Operation enabled Yes No -

03 Jog active Yes No -

04 No coasting active OFF2 inactive OFF2 active -

05 No Quick Stop active OFF3 inactive OFF3 active -

06 Power-on inhibit active Yes No -

07 Drive ready Yes No -

08 Controller enable Yes No -

09 Control requested Yes No -

11 Pulses enabled Yes No -

12 Holding brake open Yes No -

13 Command close holding brake Yes No -

14 Pulse enable from the brake control Yes No -

15 Setpoint enable from the brake control Yes No -
