Parameters
List of parameters
1-384
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the status word of the speed controller.
Note: Re bit 04:
The following conditions must be fulfilled to set to 1:
- CI: p1190 and CI: p1191 must be interconnected with a signal source that is not equal to zero.
- it is not permissible that OFF1, OFF3 or STOP2 are active.
- it is not permissible that the motor data identification is active.
- it is not permissible that the master control is active.
The following conditions can mean that the DSC function is not active in spite of the fact that the bit is set:
- clock-cycle synchronous operation is not selected (r2054 not equal to 4).
- the PROFIBUS is not clock-cycle synchronous (r2064[0] not equal to 1).
- DSC is not switched-in on the control side; this means that KPC = 0 is transferred as value at CI: p1191.
Description: Displays the status word of the velocity controller.
Note: Re bit 04:
The following conditions must be fulfilled to set to 1:
- CI: p1190 and CI: p1191 must be interconnected with a signal source that is not equal to zero.
r1407.0...13 CO/BO: Status word speed controller / ZSW n_ctrl
SERVO Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: 1530, 2522
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 V/f control active Yes No -
01 Sensorless operation active Yes No -
02 Torque control active Yes No -
04 Speed setpoint from DSC Yes No 2522
05 Speed controller I component frozen Yes No -
06 Speed controller I component set Yes No -
07 Torque limit reached Yes No 5610
08 Upper torque limit active Yes No 5610
09 Lower torque limit active Yes No 5610
11 Speed setpoint limited Yes No -
13 Sensorless operation due to a fault Yes No -
r1407.0...13 CO/BO: Status word, velocity controller / ZSW v_ctrl
SERVO (Lin) Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: 1530, 2522
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 V/f control active Yes No -
01 Sensorless operation active Yes No -
02 Force control active Yes No -
04 Velocity setpoint from DSC Yes No 2522
05 Velocity controller I component frozen Yes No -
06 Velocity controller I component set Yes No -
07 Force limit reached Yes No 5610
08 Upper force limit active Yes No 5610
09 Lower force limit active Yes No 5610
11 Velocity setpoint limited Yes No -
13 Sensorless operation due to a fault Yes No -
