EDMA3 Registers
www.ti.com
11.4.2.6 Read Rate Register (RDRATE)
The EDMA3 transfer controller issues read commands at a rate controlled by the read rate register
(RDRATE). The RDRATE defines the number of idle cycles that the read controller must wait before
issuing subsequent commands. This applies both to commands within a transfer request packet (TRP)
and for commands that are issued for different transfer requests (TRs). For instance, if RDRATE is set to
4 cycles between reads, there are 3 inactive cycles between reads.
RDRATE allows flexibility in transfer controller access requests to an endpoint. For an application,
RDRATE can be manipulated to slow down the access rate, so that the endpoint may service requests
from other masters during the inactive EDMA3TC cycles.
The RDRATE is shown in Figure 11-114 and described in Table 11-99.
NOTE: It is expected that the RDRATE value for a transfer controller is static, as it is decided based
on the application requirement. It is not recommended to change this setting on the fly.
Figure 11-114. Read Rate Register (RDRATE)
31 16
Reserved
R-0
15 3 2 0
Reserved RDRATE
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 11-99. Read Rate Register (RDRATE) Field Descriptions
Bit Field Value Description
31-3 Reserved 0 Reserved. Always write 0 to this bit; writes of 1 to this bit are not supported and attempts to do so may
result in undefined behavior.
2-0 RDRATE 0-7h Read rate. Controls the number of cycles between read commands. This is a global setting that applies
to all TRs for this EDMA3TC.
0 Reads issued as fast as possible.
1h 4 cycles between reads.
2h 8 cycles between reads.
3h 16 cycles between reads.
4h 32 cycles between reads.
5h-7h Reserved.
1004
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
