Ethernet Subsystem Registers
www.ti.com
14.5.9.8 C0_MISC_EN Register (offset = 1Ch) [reset = 0h]
C0_MISC_EN is shown in Figure 14-204 and described in Table 14-222.
SUBSYSTEM CORE 0 MISC INTERRUPT ENABLE REGISTER
Figure 14-204. C0_MISC_EN Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved C0_MISC_EN
R-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-222. C0_MISC_EN Register Field Descriptions
Bit Field Type Reset Description
31-5 Reserved R 0h
4-0 C0_MISC_EN R/W 0h Core 0 Misc Enable - Each bit in this register corresponds to the
miscellaneous interrupt (evnt_pend, stat_pend, host_pend,
mdio_linkint, mdio_userint) that is enabled to generate an interrupt
on C0_Misc_PULSE.
Bit 4 = evnt_pend
Bit 3 = stat_pend
Bit 2 = host_pend
Bit 1 = mdio_linkint
Bit 0 = mdio_userint
