GPIO Registers
www.ti.com
25.4.1.20 GPIO_LEVELDETECT1 Register (offset = 144h) [reset = 0h]
GPIO_LEVELDETECT1 is shown in Figure 25-26 and described in Table 25-25.
The GPIO_LEVELDETECT1 register is used to enable/disable for each input lines the high-level (1)
detection to be used for the interrupt request generation. Enabling at the same time high-level detection
and low-level detection for one given pin makes a constant interrupt generator.
Figure 25-26. GPIO_LEVELDETECT1 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
LEVELDETECT1[n]
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 25-25. GPIO_LEVELDETECT1 Register Field Descriptions
Bit Field Type Reset Description
31-0 LEVELDETECT1[n] R/W 0h
High Level Interrupt Enable
0x0 = Disable the IRQ assertion on high-level detect.
0x1 = Enable the IRQ assertion on high-level detect.
4088
General-Purpose Input/Output SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
