DCAN Registers www.ti.com
23.4.41 IF2ARB Register (offset = 128h) [reset = 0h]
IF2ARB is shown in Figure 23-59 and described in Table 23-54.
The bits of the IF2 arbitration registers mirror the arbitration bits of a message object. While Busy bit of IF2
command register is one, IF2 register set is write protected.
Figure 23-59. IF2ARB Register
31 30 29 28 27 26 25 24
MsgVal Xtd Dir ID28_to_ID0
R/WP-0h R/WP-0h R/WP-0h R/WP-0h
23 22 21 20 19 18 17 16
ID28_to_ID0
R/WP-0h
15 14 13 12 11 10 9 8
ID28_to_ID0
R/WP-0h
7 6 5 4 3 2 1 0
ID28_to_ID0
R/WP-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 23-54. IF2ARB Register Field Descriptions
Bit Field Type Reset Description
31 MsgVal R/WP 0h Message valid.
The CPU should reset the MsgVal bit of all unused Messages
Objects during the initialization before it resets bit Init in the CAN
control register.
This bit must also be reset before the identifier ID28 to ID0, the
control bits Xtd, Dir or DLC3 to DLC0 are modified, or if the
messages object is no longer required.
0x0 = The message object is ignored by the message handler.
0x1 = The message object is to be used by the message handler.
30 Xtd R/WP 0h
Extended identifier
0x0 = The 11-bit (standard) Identifier is used for this message object.
0x1 = The 29-bit (extended) Identifier is used for this message
object.
29 Dir R/WP 0h
Message direction
0x0 = Direction = receive: On TxRqst, a remote frame with the
identifier of this message object is transmitted. On reception of a
data frame with matching identifier, this message is stored in this
message object.
0x1 = Direction = transmit: On TxRqst, the respective message
object is transmitted as a data frame. On reception of a remote
frame with matching identifier, the TxRqst bit of this message object
is set (if RmtEn = 1).
28-0 ID28_to_ID0 R/WP 0h Message identifier.
ID28 to ID0 is equal to
29-bit identifier (extended frame) ID28 to ID18 is equal to
11-bit identifier (standard frame)
3972
Controller Area Network (CAN) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
