ELM
www.ti.com
7.4.5.16 ELM_ERROR_LOCATION_0-15_i Registers
The ELM_ERROR_LOCATION_0-15_i Registers is shown in Figure 7-156 and described in Table 7-190.
Figure 7-156. ELM_ERROR_LOCATION_0-15_i Registers
31 13 12 0
Reserved ECC_ERROR_LOCATION
R-0 R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-190. ELM_ERROR_LOCATION_0-15_i Registers Field Descriptions
Bit Field Value Description
31-13 Reserved 0 Reserved
12-0 ECC_ERROR_LOCATION 0-1FFFh Error-location bit address.
498
Memory Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
