16.5.7.1126 QUEUE_155_STATUS_C Register (offset = 39B8h) [reset = 0h]
QUEUE_155_STATUS_C is shown in Figure 16-1402 and described in Table 16-1416.
Figure 16-1402. QUEUE_155_STATUS_C Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved PACKET_SIZE
R-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-1416. QUEUE_155_STATUS_C Register Field Descriptions
Bit Field Type Reset Description
13-0 PACKET_SIZE R-0 0 This field indicates packet size of the head element of a queue.
Queue_Manager_Queue_N_Status_C Registers C
