DMTimer 1ms
www.ti.com
20.2.2.3 Timer Clock Signals
Table 20-29. Timer Clock Signals
Clock Signal Max Freq Reference / Source Comments
Timer1 (1ms) Clock Signals
PICLKOCP 100 MHz CORE_CLKOUTM4 / 2 pd_wkup_l4_wkup_gclk
Interface clock from PRCM
PICLKTIMER 25 MHz
(1)
pd_wkup_timer1_gclk
CLK_M_OSC
Functional clock from PRCM
CLK_32KHZ
(PER_CLKOUTM2 / 5859.375)
TCLKIN
CLK_RC32K
CLK_32K_RTC
(1)
PICLKTIMER must be less than PICLKOCP/4.
