Functional Description
www.ti.com
By default, all channels map to PaRAM set to 0. These should be remapped before use. For more
information, see Section 11.4.1.1.4 (DCHMAP registers) and Section 11.4.1.1.5 (QCHMAP registers).
Table 11-5. EDMA3 Parameter RAM Contents
PaRAM Set Number Address Parameters
0 EDMA Base Address + 4000h to EDMA Base PaRAM set 0
Address + 401Fh
1 EDMA Base Address + 4020h to EDMA Base PaRAM set 1
Address + 403Fh
2 EDMA Base Address + 4040h to EDMA Base PaRAM set 2
Address + 405Fh
3 EDMA Base Address + 4060h to EDMA Base PaRAM set 3
Address + 407Fh
4 EDMA Base Address + 4080h to EDMA Base PaRAM set 4
Address + 409Fh
5 EDMA Base Address + 40A0h to EDMA Base PaRAM set 5
Address + 40BFh
6 EDMA Base Address + 40C0h to EDMA Base PaRAM set 6
Address + 40DFh
7 EDMA Base Address + 40E0h to EDMA Base PaRAM set 7
Address + 40FFh
8 EDMA Base Address + 4100h to EDMA Base PaRAM set 8
Address + 411Fh
9 EDMA Base Address + 4120h to EDMA Base PaRAM set 9
Address + 413Fh
... ... ...
63 EDMA Base Address + 47E0h to EDMA Base PaRAM set 63
Address + 47FFh
64 EDMA Base Address + 4800h to EDMA Base PaRAM set 64
Address + 481Fh
65 EDMA Base Address + 4820h to EDMA Base PaRAM set 65
Address + 483Fh
... ... ...
254 EDMA Base Address + 5FC0h to EDMA Base PaRAM set 254
Address + 5FDFh
255 EDMA Base Address + 5FE0h to EDMA Base PaRAM set 255
Address + 5FFFh
11.3.3.1 PaRAM
Each parameter set of PaRAM is organized into eight 32-bit words or 32 bytes, as shown in Figure 11-9
and described in Table 11-6. Each PaRAM set consists of 16-bit and 32-bit parameters.
882
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
