Multimedia Card Registers www.ti.com
18.5.1.14 SD_RSP76 Register (offset = 21Ch) [reset = 0h]
SD_RSP76 is shown in Figure 18-50 and described in Table 18-33.
This 32-bit register holds bits positions [127:96] of command response type R2.
Figure 18-50. SD_RSP76 Register
31 30 29 28 27 26 25 24
RSP7
R-0h
23 22 21 20 19 18 17 16
RSP7
R-0h
15 14 13 12 11 10 9 8
RSP6
R-0h
7 6 5 4 3 2 1 0
RSP6
R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 18-33. SD_RSP76 Register Field Descriptions
Bit Field Type Reset Description
31-16 RSP7 R 0h Command Response
[127:112]
15-0 RSP6 R 0h Command Response
[111:96]
