EDMA3 Registers
www.ti.com
11.4.1.6.4 Chained Event Registers (CER, CERH)
When the OPTIONS parameter for a PaRAM entry is programmed to returned a chained completion code
(ITCCHEN = 1 and/or TCCHEN = 1), then the value dictated by the TCC[5:0] (also programmed in OPT)
forces the corresponding event bit to be set in the chained event registers (CER/CERH). The set chained
event is evaluated by the EDMA3CC logic for an associated transfer request submission to the transfer
controllers. This results in a chained-triggered transfer.
The chained event registers do not have any enables. The generation of a chained event is essentially
enabled by the PaRAM entry that has been configured for intermediate and/or final chaining on transfer
completion. The En bit is set (regardless of the state of EER.En/EERH.En) when a chained completion
code is returned from one of the transfer controllers or is generated by the EDMA3CC via the early
completion path. The bits in the chained event register are cleared when the corresponding events are
prioritized and serviced.
If the En bit is already set and another chaining completion code is return for the same event, then the
corresponding event is latched in the event missed registers (EMR.En/EMRH.En = 1). The setting of an
event is a higher priority relative to clear operations (via hardware). If set and clear conditions occur
concurrently, the set condition wins. If the event was previously set, then EMR/EMRH would be set
because an event is lost. If the event was previously clear, then the event remains set and is prioritized for
submission to the event queues.
The CER is shown in Figure 11-76 and described in Table 11-60. The CERH is shown in Figure 11-77
and described in Table 11-61.
Figure 11-76. Chained Event Register (CER)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
E31 E30 E29 E28 E27 E26 E25 E24 E23 E22 E21 E20 E19 E18 E17 E16
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 11-60. Chained Event Register (CER) Field Descriptions
Bit Field Value Description
31-0 En Chained event for event 0-31.
0 No effect.
1 Corresponding DMA event is prioritized versus other pending DMA/QDMA events for submission to the
EDMA3TC.
Figure 11-77. Chained Event Register High (CERH)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
E63 E62 E61 E60 E59 E58 E57 E56 E55 E54 E53 E52 E51 E50 E49 E48
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E47 E46 E45 E44 E43 E42 E41 E40 E39 E38 E37 E36 E35 E34 E33 E32
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
974
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
