www.ti.com
Enhanced Quadrature Encoder Pulse (eQEP) Module
15.4.3.12 QEP Decoder Control Register (QDECCTL)
Figure 15-160. QEP Decoder Control Register (QDECCTL)
15 14 13 12 11 10 9 8
QSRC SOEN SPSEL XCR SWAP IGATE QAP
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 0
QBP QIP QSP Reserved
R/W-0 R/W-0 R/W-0 R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 15-135. eQEP Decoder Control Register (QDECCTL) Field Descriptions
Bits Name Value Description
15-14 QSRC 0-3h Position-counter source selection
0 Quadrature count mode (QCLK = iCLK, QDIR = iDIR)
1h Direction-count mode (QCLK = xCLK, QDIR = xDIR)
2h UP count mode for frequency measurement (QCLK = xCLK, QDIR = 1)
3h DOWN count mode for frequency measurement (QCLK = xCLK, QDIR = 0)
13 SOEN Sync output-enable
0 Disable position-compare sync output
1 Enable position-compare sync output
12 SPSEL Sync output pin selection
0 Index pin is used for sync output
1 Strobe pin is used for sync output
11 XCR External clock rate
0 2× resolution: Count the rising/falling edge
1 1× resolution: Count the rising edge only
10 SWAP Swap quadrature clock inputs. This swaps the input to the quadrature decoder, reversing the counting
direction.
0 Quadrature-clock inputs are not swapped
1 Quadrature-clock inputs are swapped
9 IGATE Index pulse gating option
0 Disable gating of Index pulse
1 Gate the index pin with strobe
8 QAP QEPA input polarity
0 No effect
1 Negates QEPA input
7 QBP QEPB input polarity
0 No effect
1 Negates QEPB input
6 QIP QEPI input polarity
0 No effect
1 Negates QEPI input
5 QSP QEPS input polarity
0 No effect
1 Negates QEPS input
4-0 Reserved 0 Always write as 0
1677
SPRUH73H–October 2011–Revised April 2013 Pulse-Width Modulation Subsystem (PWMSS)
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
