16.5.1.9 IRQDMATHOLDTX02 Register (offset = 108h) [reset = 0h]
IRQDMATHOLDTX02 is shown in Figure 16-30 and described in Table 16-38.
Figure 16-30. IRQDMATHOLDTX02 Register
31 30 29 28 27 26 25 24
DMA_THRES_TX0_11
R/W-0h
23 22 21 20 19 18 17 16
DMA_THRES_TX0_10
R/W-0h
15 14 13 12 11 10 9 8
DMA_THRES_TX0_9
R/W-0h
7 6 5 4 3 2 1 0
DMA_THRES_TX0_8
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-38. IRQDMATHOLDTX02 Register Field Descriptions
Bit Field Type Reset Description
31-24 DMA_THRES_TX0_11 R/W 0h DMA threshold value for tx_pkt_cmp_0 for USB0 Endpoint 11.
23-16 DMA_THRES_TX0_10 R/W 0h DMA threshold value for tx_pkt_cmp_0 for USB0 Endpoint 10.
15-8 DMA_THRES_TX0_9 R/W 0h
DMA threshold value for tx_pkt_cmp_0 for USB0 Endpoint 9.
7-0 DMA_THRES_TX0_8 R/W 0h DMA threshold value for tx_pkt_cmp_0 for USB0 Endpoint 8.
USBSS IRQ_DMA_THRSHOLD_TX0_2 Register
