23.4.44 IF2DATB Register (offset = 134h) [reset = 0h]
IF2DATB is shown in Figure 23-62 and described in Table 23-57.
The data bytes of CAN messages are stored in the IF2 registers in the following order: (1) In a CAN data
frame, Data 0 is the first, and Data 7 is the last byte to be transmitted or received. (2) In CAN's serial bit
stream, the MSB of each byte will be transmitted first.
Figure 23-62. IF2DATB Register
31 30 29 28 27 26 25 24
Data_7
R/WP-0h
23 22 21 20 19 18 17 16
Data_6
R/WP-0h
15 14 13 12 11 10 9 8
Data_5
R/WP-0h
7 6 5 4 3 2 1 0
Data_4
R/WP-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 23-57. IF2DATB Register Field Descriptions
Bit Field Type Reset Description
31-24 Data_7 R/WP 0h
Data 7.
23-16 Data_6 R/WP 0h
Data 6.
15-8 Data_5 R/WP 0h
Data 5.
7-0 Data_4 R/WP 0h
Data 4.
