EDMA3 Registers
11.4.2.5 Error Registers
11.4.2.5.1 Error Register (ERRSTAT)
The error status register (ERRSTAT) is shown in Figure 11-109 and described in Table 11-94.
Figure 11-109. Error Register (ERRSTAT)
31 16
Reserved
R-0
15 4 3 2 1 0
Reserved MMRAERR TRERR Reserved BUSERR
R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 11-94. Error Register (ERRSTAT) Field Descriptions
Bit Field Value Description
31-4 Reserved 0 Reserved. Always write 0 to this bit; writes of 1 to this bit are not supported and attempts to do so may
result in undefined behavior.
3 MMRAERR MMR address error.
0 Condition is not detected.
1 User attempted to read or write to an invalid address in configuration memory map.
2 TRERR Transfer request (TR) error event.
0 Condition is not detected.
1 TR detected that violates constant addressing mode transfer (SAM or DAM is set) alignment rules or
has ACNT or BCNT == 0.
1 Reserved 0 Reserved. Always write 0 to this bit; writes of 1 to this bit are not supported and attempts to do so may
result in undefined behavior.
0 BUSERR Bus error event.
0 Condition is not detected.
1 EDMA3TC has detected an error at source or destination address. Error information can be read from
the error details register (ERRDET).
