USB Registers
16.5.7.11 LRAM0BASE Register (offset = 80h) [reset = 0h]
LRAM0BASE is shown in Figure 16-287 and described in Table 16-301.
Figure 16-287. LRAM0BASE Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
REGION0_BASE Reserved
R/W-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-301. LRAM0BASE Register Field Descriptions
Bit Field Type Reset Description
31-2 REGION0_BASE R/W-0 0 This field stores the base address for the first region of the linking
RAM.
This may be anywhere in
32-bit address space but would be typically located in on-chip
memory.
