USB Registers
16.5.7.1 QMGRREVID Register (offset = 0h) [reset = 4E530800h]
QMGRREVID is shown in Figure 16-277 and described in Table 16-291.
Figure 16-277. QMGRREVID Register
31 30 29 28 27 26 25 24
SCHEME Reserved FUNCTION
R-0 R-0
23 22 21 20 19 18 17 16
FUNCTION
R-0
15 14 13 12 11 10 9 8
REVRTL REVMAJ
R-0 R-0
7 6 5 4 3 2 1 0
REVCUSTOM REVMIN
R-0 R-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-291. QMGRREVID Register Field Descriptions
Bit Field Type Reset Description
31-30 SCHEME R-0 0
Scheme that this register is compliant with
27-16 FUNCTION R-0 0
Function
15-11 REVRTL R-0 0
RTL revision
10-8 REVMAJ R-0 0
Major revision
7-6 REVCUSTOM R-0 0
Custom revision
5-0 REVMIN R-0 0
Minor revision Queue Manager Revision Register
2109
SPRUH73H–October 2011–Revised April 2013 Universal Serial Bus (USB)
Submit Documentation Feedback
