Touchscreen Controller Registers
www.ti.com
12.5.1.54 FIFO1COUNT Register (offset = F0h) [reset = 0h]
FIFO1COUNT is shown in Figure 12-58 and described in Table 12-58.
FIFO1 word count@TSC_ADC_SS_FIFO1 Word Count Register
Figure 12-58. FIFO1COUNT Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved Words_in_FIFO0
R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-58. FIFO1COUNT Register Field Descriptions
Bit Field Type Reset Description
31-7 Reserved R 0h
RESERVED
6-0 Words_in_FIFO0 R 0h
Number of words currently in the FIFO0
1092
Touchscreen Controller SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
