USB Registers www.ti.com
16.5.4.15 AD_INTERFACE_REG1 Register (offset = 44h) [reset = 0h]
AD_INTERFACE_REG1 is shown in Figure 16-148 and described in Table 16-159.
All bits (unless defined) are bypass bits for internal analog to digital interface pins with the same name. All
the bits of this register, except the over-ride bits return a '0' on read, if VDDLDO is off.
Figure 16-148. AD_INTERFACE_REG1 Register
31 30 29 28 27 26 25 24
USE_AD_DATA_REG HS_TX_DATA FS_TX_DATA TEST_PRE_EN_CNT SQ_PRE_EN HS_TX_PRE_EN HS_RX_PRE_EN TEST_EN_CNTRL
RL
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h
23 22 21 20 19 18 17 16
HS_TX_EN FS_RX_EN Reserved SQ_EN HS_RX_EN TEST_HS_MODE HS_HV_SW HS_CHIRP
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h
15 14 13 12 11 10 9 8
TEST_FS_MODE FSTX_GZ FSTX_PRE_EN Reserved TEST_SQ_CAL_CON SQ_CAL_EN3 SQ_CAL_EN1 SQ_CAL_EN2
TROL
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h
7 6 5 4 3 2 1 0
TEST_RTERM_CAL_ RTERM_CAL_EN DLL_RX_DATA DISCON_DETECT USE_LSHOST_REG LSHOSTMODE LSFS_RX_DATA SQUELCH
CONTROL
R/W-0h R/W-0h R-0h R-0h R/W-0h R/W-0h R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-159. AD_INTERFACE_REG1 Register Field Descriptions
Bit Field Type Reset Description
31 USE_AD_DATA_REG R/W 0h Override for bits
30-29
30 HS_TX_DATA R/W 0h
29 FS_TX_DATA R/W 0h
28 TEST_PRE_EN_CNTRL R/W 0h Override for bits
27-25
27 SQ_PRE_EN R/W 0h
26 HS_TX_PRE_EN R/W 0h
25 HS_RX_PRE_EN R/W 0h
24 TEST_EN_CNTRL R/W 0h Override for bits
23-19
23 HS_TX_EN R/W 0h
22 FS_RX_EN R/W 0h
21 Reserved R/W 0h
20 SQ_EN R/W 0h
19 HS_RX_EN R/W 0h
18 TEST_HS_MODE R/W 0h Override for bits
17-16
17 HS_HV_SW R/W 0h
16 HS_CHIRP R/W 0h
15 TEST_FS_MODE R/W 0h
Override for bits 14 12
14 FSTX_GZ R/W 0h
13 FSTX_PRE_EN R/W 0h
12 Reserved R/W 0h
11 TEST_SQ_CAL_CONTR R/W 0h
Override for bits 10 8
OL
10 SQ_CAL_EN3 R/W 0h
1920
