Touchscreen Controller Registers
www.ti.com
12.5.1.14 ADC_MISC Register (offset = 50h) [reset = 0h]
ADC_MISC is shown in Figure 12-18 and described in Table 12-18.
AFE misc debug@TSC_ADC_SS_MISC Register
Figure 12-18. ADC_MISC Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
AFE_Spare_Output AFE_Spare_Input
R-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-18. ADC_MISC Register Field Descriptions
Bit Field Type Reset Description
31-8 Reserved R 0h
RESERVED.
7-4 AFE_Spare_Output R 0h Connected to AFE Spare Output pins.
Reserved in normal operation.
3-0 AFE_Spare_Input R/W 0h Connected to AFE Spare Input pins.
Reserved in normal operation.
1052
Touchscreen Controller SPRUH73H–October 2011–Revised April 2013
