www.ti.com

UART Registers

19.5.1.51 FREQ_SEL Register

The FREQ_SEL register (FREQ_SEL) is shown in Figure 19-84 and described in Table 19-83.

Figure 19-84. FREQ_SEL Register

31 8 7 0

Reserved FREQ_SEL

R-0 R/W-1A

LEGEND: R/W = Read/Write; R = Read only; -n = value after reset

Table 19-83. FREQ_SEL Register Field Descriptions

Bit Field Value Description

31-8 Reserved 0 Reserved.

7-0 FREQ_SEL 1A Sets the sample per bit if non default frequency is used. MDR3[1] must be set to 1 after this value

is set. Must be equal or higher then 6.

3547

SPRUH73H–October 2011–Revised April 2013 Universal Asynchronous Receiver/Transmitter (UART)
