CONTROL_MODULE Registers
9.3.57 tpcc_evt_mux_4_7 Register (offset = F94h) [reset = 0h]
tpcc_evt_mux_4_7 is shown in Figure 9-60 and described in Table 9-67.
Figure 9-60. tpcc_evt_mux_4_7 Register
31 30 29 28 27 26 25 24
Reserved evt_mux_7
R-0h R/W-0h
23 22 21 20 19 18 17 16
Reserved evt_mux_6
R-0h R/W-0h
15 14 13 12 11 10 9 8
Reserved evt_mux_5
R-0h R/W-0h
7 6 5 4 3 2 1 0
Reserved evt_mux_4
R-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 9-67. tpcc_evt_mux_4_7 Register Field Descriptions
Bit Field Type Reset Description
31-30 Reserved R 0h
29-24 evt_mux_7 R/W 0h Selects 1 of 64 inputs for DMA event 7
23-22 Reserved R 0h
21-16 evt_mux_6 R/W 0h Selects 1 of 64 inputs for DMA event 6
15-14 Reserved R 0h
13-8 evt_mux_5 R/W 0h Selects 1 of 64 inputs for DMA event 5
7-6 Reserved R 0h
5-0 evt_mux_4 R/W 0h Selects 1 of 64 inputs for DMA event 4
