GPIO Registers
www.ti.com
25.4.1.18 GPIO_DATAOUT Register (offset = 13Ch) [reset = 0h]
GPIO_DATAOUT is shown in Figure 25-24 and described in Table 25-23.
The GPIO_DATAOUT register is used for setting the value of the GPIO output pins. Data is written to the
GPIO_DATAOUT register synchronously with the interface clock. This register can be accessed with
direct read/write operations or using the alternate Set/Clear feature. This feature enables to set or clear
specific bits of this register with a single write access to the set data output register
(GPIO_SETDATAOUT) or to the clear data output register (GPIO_CLEARDATAOUT) address.
Figure 25-24. GPIO_DATAOUT Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DATAOUT
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 25-23. GPIO_DATAOUT Register Field Descriptions
Bit Field Type Reset Description
31-0 DATAOUT R/W 0h
Data to set on output pins
4086
General-Purpose Input/Output SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
