16.5.1.13 IRQDMATHOLDRX02 Register (offset = 118h) [reset = 0h]
IRQDMATHOLDRX02 is shown in Figure 16-34 and described in Table 16-42.
Figure 16-34. IRQDMATHOLDRX02 Register
31 30 29 28 27 26 25 24
DMA_THRES_RX0_11
R/W-0h
23 22 21 20 19 18 17 16
DMA_THRES_RX0_10
R/W-0h
15 14 13 12 11 10 9 8
DMA_THRES_RX0_9
R/W-0h
7 6 5 4 3 2 1 0
DMA_THRES_RX0_8
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-42. IRQDMATHOLDRX02 Register Field Descriptions
Bit Field Type Reset Description
31-24 DMA_THRES_RX0_11 R/W 0h DMA threshold value for rx_pkt_cmp_0 for USB0 Endpoint 11.
23-16 DMA_THRES_RX0_10 R/W 0h DMA threshold value for rx_pkt_cmp_0 for USB0 Endpoint 10.
15-8 DMA_THRES_RX0_9 R/W 0h
DMA threshold value for rx_pkt_cmp_0 for USB0 Endpoint 9.
7-0 DMA_THRES_RX0_8 R/W 0h DMA threshold value for rx_pkt_cmp_0 for USB0 Endpoint 8.
USBSS IRQ_DMA_THRSHOLD_RX0_2 Register
