www.ti.com
DMTimer
20.1.5.1 TIDR Register (offset = 00h) [reset = 40000100h]
TIDR is shown in Figure 20-9 and described in Table 20-11.
This read only register contains the revision number of the module. A write to this register has no effect.
This register is used by software to track features, bugs, and compatibility.
Figure 20-9. TIDR Register
31 30 29 28 27 26 25 24
SCHEME Reserved FUNC
R/W-1h R-0h R/W-0h
23 22 21 20 19 18 17 16
FUNC
R/W-0h
15 14 13 12 11 10 9 8
R_RTL X_MAJOR
R/W-0h R/W-1h
7 6 5 4 3 2 1 0
CUSTOM Y_MINOR
R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 20-11. TIDR Register Field Descriptions
Bit Field Type Reset Description
31-30 SCHEME R/W 1h
Used to distinguish between old scheme and current.
29-28 Reserved R 0h
27-16 FUNC R/W 0h
Function indicates a software compatible module family.
15-11 R_RTL R/W 0h
RTL Version (R).
10-8 X_MAJOR R/W 1h
Major Revision (X).
7-6 CUSTOM R/W 0h
Indicates a special version for a particular device.
5-0 Y_MINOR R/W 0h
Minor Revision (Y).
3567
SPRUH73H–October 2011–Revised April 2013 Timers
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
